OB20

PDF Download

CHASSIS

​

  • 10.8m long rigid vehicle

  • Single partial expanding side (can operate with side in or out)

  • Self-levelling system

  • Air-conditioning and roof platform

​

WEIGHT

​

  • 18 tonnes

​

POWER

​

  • 1 x 125amp single phase c-form

Maximising available space.

​

OB20 is a unique and powerful truck designed to provide optimum internal space and yet cope with venues where access and/or parking are restricted. This is the first HD truck in the market to be able to operate fully with its expanding side in or out.

​

With the expanding side out the Production area offers two spacious rows of seating. The front row seats up to 5 people and the second row a further 2 people all with room to spare. However with the expanding side in, the truck is fully operational but simply without the second row of Production seating being available.

Layout
